该文将介绍如何使用spire.xls 在.net应用程序中通过设置线条起点和终点，然后以这两个点的位置添加线条到excel工作表。线条起点和终点的位置可以为相对位置或绝对位置。详细代码：

using spire.xls;
using spire.xls.core.spreadsheet.shapes;
using system.drawing;
namespace addlinestoexcel
{
    class program
    {
        static void main(string[] args)
        {
            //新建workbook并获取第一个工作表
            workbook workbook = new workbook();
            worksheet worksheet = workbook.worksheets[0];
            //通过相对位置添加线条
            xlslineshape line = worksheet.typedlines.addline() as xlslineshape;
            //设置线条起点位置
            line.leftcolumn = 2;
            line.leftcolumnoffset = 2;
            line.toprow = 5;
            line.toprowoffset = 10;
            //设置线条终点位置
            line.rightcolumn = 10;
            line.rightcolumnoffset = 10;
            line.bottomrow =5;
            line.bottomrowoffset = 10;
            //设置线条颜色
            line.color = color.red;
            //通过绝对位置添加线条，单位为像素
            xlslineshape line1 = worksheet.typedlines.addline() as xlslineshape;
            //设置线条起点和终点位置
            line1.startpoint = new point(20, 30);
            line1.endpoint = new point(200, 30);
            //设置线条颜色
            line1.color = color.blue;

            workbook.savetofile("addlines.xlsx", excelversion.version2013);
            workbook.dispose();
        }
    }
 }

imports spire.xls
imports spire.xls.core.spreadsheet.shapes
imports system.drawing
namespace addlinestoexcel

    class program

        private shared sub main(byval args() as string)
            '新建workbook并获取第一个工作表
            dim workbook as workbook = new workbook
            dim worksheet as worksheet = workbook.worksheets(0)
            '通过相对位置添加线条
            dim line as xlslineshape = ctype(worksheet.typedlines.addline,xlslineshape)
            '设置线条起点位置
            line.leftcolumn = 2
            line.leftcolumnoffset = 2
            line.toprow = 5
            line.toprowoffset = 10
            '设置线条终点位置
            line.rightcolumn = 10
            line.rightcolumnoffset = 10
            line.bottomrow = 5
            line.bottomrowoffset = 10
            '设置线条颜色
            line.color = color.red
            //通过绝对位置添加线条，单位为像素
            dim line1 as xlslineshape = ctype(worksheet.typedlines.addline,xlslineshape)
            '设置线条起点和终点位置
            line1.startpoint = new point(20, 30)
            line1.endpoint = new point(200, 30)
            '设置线条颜色
            line1.color = color.blue
            workbook.savetofile("addlines.xlsx", excelversion.version2013)
            workbook.dispose
        end sub
    end class
end namespace

效果图：
